S&B 10-1003 70 Gallon Replacement Fuel Tank | 2011-2016 Ford F250/F350 6.7L Powerstroke Crew Cab/Long Bed

Features:

• 70 Gallon Capacity (double OEM capacity!)
• Midship Placement
• Direct Factory Replacement Tank
• Holds 5 More Gallons than Competitors
• Quick Install
• Uses Factory OE Sending Unit

70 Gallon Replacement Tank For 2011-2016 Ford Powerstroke 6.7L, Crew Cab Long Bed. S&B's 70 gallon fuel tank replaces the OEM 35 gallon fuel tank. The replacement tank sits 3" below the OEM fuel tank shield and hold approximately 70 gallons of fuel. The float's empty position in the S&B Tank is the same as the OEM tank. Since the bottom surface area on the S&B Tank is larger, the 70 Gallon tank with have a greater fuel reserve.

Install can be done in 2-3 hours and does not require any cutting, drilling or modification.

Specifications:

• TANK TYPE:  MIDSHIP
• S&B CAPACITY (APPROXIMATE):  70 GALLONS
• WEIGHT (DRY):  53LBS
• GROUND CLEARANCE COMPARE TO OE TANK:  3" LOWER
• SUMP:  NO
• DRAIN:  YES
• SENDING UNIT:  OE
• STRAPS INCLUDED:  YES
• COMPATIBLE WITH OE SKID PLATE:  NO
• COMPATIBLE WITH GOOSENECK AND 5TH WHEEL:  YES
• TRANSFER PUMP READY:  YES
• EMBEDDED FITTING THREAD SIZE:  1/2" NPT
• DIMENSIONS:  80.82" X 19.18" X 20.79"
